EDGE AI Sensing Kit
COST EFFECTIVE EDGE-AI CAMERA
Powered by the STM32N6, the EDGE AI Sensing Kit is a smart camera designed for Tiny-ML!
Based on SIANA’s N6Cam design, manufactured by e2IP Technologies..
The EDGE AI Sensing Kit, powered by a production-grade BSP, empowers you to smoothly transition from lab prototypes to real-world edge-AI deployments. Get your experiments out of the lab and into action!
“The future of Ai-powered mcus”
A modular design (3x PCBs) allows for flexible productization:
Compute Module:
STM32N657 includes:
Cortex-M55 @ 800MHz, 1280 DMIPS, 32 KB I/DCache
ST Neural-ART Accelerator @ 1GHz, 600 Gops, 288 MAC/cycle
4.2 Mbytes of SRAM
H264 encoder: 1080p30, 720p60
One MIPI-CSI interface (2-lanes)
External Memory:
64MB of external NOR Flash
32MB of external SDRAM
Onboard Sensors:
STHS34PF80 Human Presence Sensor
VL53L7CH Time-of-Flight Ranging Sensor
LSM6DSO32 Inertial Sensor
2x MP34DT05-A Microphones
micro SDCard
Camera Module:
Sony 5Mpx IMX335 HDR sensor
M12 mount (with default lense)
2x IR LEDs
Push-Button + LED
IO Module:
USB-C connector:
data: USB DRP / HS
power: 5V @ 1A
Expansion Header: IO, I2C, SPI, UART, Power
Optional: WiFi/BT module from Murata (Type 2GF)
** get yours now **
The EDGE AI Sensing Kit is available
for purchase from the e2IP web store:
** SupporT **
When you’re ready to develop, go to:
